Dell Precision™ T3500 Service Manual--Working on Your Computer
file:///C|/Biz%20Client/2015/NewBalance/Info%20Dev%20Root/New%20Balance/SM/A00/EN/Source/work.htm[5/15/2015 11:40:56 AM]
The procedures in this document may require the following tools:
Small flat-blade screwdriver
Phillips screwdriver
Small plastic scribe
Flash BIOS update program CD (see the Dell Support website at support.dell.com)
Turning Off Your Computer
CAUTION: To avoid losing data, save and close all open files and exit all open programs before you turn off
your computer.
1. Shut down the operating system:
In Windows Vista:
Click Start
, then click the arrow in the lower-right corner of the Start menu as shown below, and then click
Shut Down.
In Windows XP:
Click Start® Turn Off Computer® Turn Off.
The computer turns off after the operating system shutdown process is complete.
2. Ensure that the computer and all attached devices are turned off. If your computer and attached devices did not
automatically turn off when you shut down your operating system, press and hold the power button for about 6
seconds to turn them off.
After Working Inside Your Computer
After you complete any replacement procedure, ensure you connect any external devices, cards, and cables before turning on
your computer.
1. Replace the computer cover (see Removing and Replacing the Cover
).
2. Connect any telephone or network cables to your computer.
CAUTION: To connect a network cable, first plug the cable into the network device and then plug it into the
computer.
3. Connect your computer and all attached devices to their electrical outlets.
4. Turn on your computer.
5. Verify that the computer works correctly by running the Dell Diagnostics. See Dell Diagnostics
.

Dell Precision T3500 Specifications

General

Tcase	67.9 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	W3550
System bus rate	4.8 GT/s
Processor series	Intel Xeon 3500 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Bloomfield
Processing Die size	263 mm²
Processor frequency	3.06 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.225 V
Number of processors installed	1
CPU multiplier (bus/core ratio)	23
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	731 M
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	24 GB
Display	LCD
Graphics card	FirePro V5900
Dimensions (WxDxH)	172 x 468 x 447 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card manufacturer	AMD
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® X58 Express
Memory slots	-
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	2 x 2 GB
HDD speed	7200 RPM
HDD capacity	500 GB
HDD interface	SATA III
Optical drive type	DVD Super Multi DL
Maximum graphics card memory	2.048 GB
Display diagonal	22 \
Display number of colors	16.78 million colors
PS/2 ports quantity	2
USB 2.0 ports quantity	11
VGA (D-Sub) ports quantity	0
Chassis type	Tower
Product color	Black, Silver
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Operating system installed	Windows XP Professional
Compatible operating systems	Windows 7
Power supply	525 W
Processor ARK ID	39720
Processor package size	42.5 x 45.0 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	468 mm
Width	172 mm
Height	447 mm
Weight	17700 g
