Dell Precision™ T3500 Service Manual--Memory
file:///C|/Biz%20Client/2015/NewBalance/Info%20Dev%20Root/New%20Balance/SM/A00/EN/Source/td_mem.htm[5/15/2015 11:41:14 AM]
Memory
Dell Precision™ T3500 Service Manual
Supported Memory Configurations
Removing and Replacing Memory Modules
Your computer uses 1066 MHz or 1333Mhz DDR3 unbuffered SDRAM memory. DDR3 SDRAM, or double-data-rate three
synchronous dynamic random access memory, is a random access memory technology. It is a part of the SDRAM family of
technologies, which is one of many DRAM (dynamic random access memory) implementations, and is an evolutionary
improvement over its predecessor, DDR2 SDRAM.
Supported Memory Configurations
Size
(GB)
DIMM
Ranks
DIMM1 DIMM2 DIMM3 DIMM4 DIMM5 DIMM6 1333MHz 1066MHz
Channel
Mode
1 SR 1 GB
Single
2 SR 1 GB 1 GB
Dual
3 SR 1 GB 1 GB 1 GB
Tri
4 SR 1 GB 1 GB 1 GB 1 GB
Tri
4 DR 2 GB 2 GB
Dual
6 SR 1 GB 1 GB 1 GB 1 GB 1 GB 1 GB
Tri
6 DR 2 GB 2 GB 2 GB
Tri
12 DR 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB
Tri
12 DR 4 GB 4 GB 4 GB
Tri
24 DR 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB
Tri
NOTE: DDR3 DIMMs have 240 pins, the same number as DDR2, and are the same size, but are electrically
incompatible and have a different key notch location.
Removing and Replacing Memory Modules
WARNING: Before working inside your computer, read the safety information that shipped with your
computer. For additional safety best practices information, see the Regulatory Compliance Homepage at
www.dell.com/regulatory_compliance.

Dell Precision T3500 Specifications

General

Tcase	67.9 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	W3550
System bus rate	4.8 GT/s
Processor series	Intel Xeon 3500 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Bloomfield
Processing Die size	263 mm²
Processor frequency	3.06 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.225 V
Number of processors installed	1
CPU multiplier (bus/core ratio)	23
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	731 M
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	24 GB
Display	LCD
Graphics card	FirePro V5900
Dimensions (WxDxH)	172 x 468 x 447 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card manufacturer	AMD
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® X58 Express
Memory slots	-
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	2 x 2 GB
HDD speed	7200 RPM
HDD capacity	500 GB
HDD interface	SATA III
Optical drive type	DVD Super Multi DL
Maximum graphics card memory	2.048 GB
Display diagonal	22 \
Display number of colors	16.78 million colors
PS/2 ports quantity	2
USB 2.0 ports quantity	11
VGA (D-Sub) ports quantity	0
Chassis type	Tower
Product color	Black, Silver
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Operating system installed	Windows XP Professional
Compatible operating systems	Windows 7
Power supply	525 W
Processor ARK ID	39720
Processor package size	42.5 x 45.0 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	468 mm
Width	172 mm
Height	447 mm
Weight	17700 g
