Dell Precision™ T3500 Service Manual--Working on Your Computer
file:///C|/Biz%20Client/2015/NewBalance/Info%20Dev%20Root/New%20Balance/SM/A00/EN/Source/work.htm[5/15/2015 11:40:56 AM]
Working on Your Computer
Dell™ Precision™ T3500 Service Manual
Before Working Inside Your Computer
Recommended Tools
Turning Off Your Computer
After Working Inside Your Computer
Before Working Inside Your Computer
Use the following safety guidelines to help protect your computer from potential damage and to help to ensure your personal
safety. Unless otherwise noted, each procedure included in this document assumes that the following conditions exist:
You have performed the steps in Working on Your Computer.
You have read the safety information that shipped with your computer.
A component can be replaced or—if purchased separately—installed by performing the removal procedure in reverse
order.
WARNING: Before working inside your computer, read the safety information that shipped with your
computer. For additional safety best practices information, see the Regulatory Compliance Homepage at
www.dell.com/regulatory_compliance.
CAUTION: Only a certified service technician should perform repairs on your computer. Damage due to
servicing that is not authorized by Dell is not covered by your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by
periodically touching an unpainted metal surface, such as a connector on the back of the computer.
CAUTION: Handle components and cards with care. Do not touch the components or contacts on a card.
Hold a card by its edges or by its metal mounting bracket. Hold a component such as a processor by its
edges, not by its pins.
CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab, not on the cable itself.
Some cables have connectors with locking tabs; if you are disconnecting this type of cable, press in on the
locking tabs before you disconnect the cable. As you pull connectors apart, keep them evenly aligned to
avoid bending any connector pins. Also, before you connect a cable, ensure that both connectors are
correctly oriented and aligned.
NOTE: The color of your computer and certain components may appear differently than shown in this document.
To avoid damaging your computer, perform the following steps before you begin working inside the computer.
1. Ensure that your work surface is flat and clean to prevent the computer cover from being scratched.
2. Turn off your computer (see Turning Off Your Computer
).
CAUTION: To disconnect a network cable, first unplug the cable from your computer and then unplug the
cable from the network device.
3. Disconnect all network cables from the computer.
5. Disconnect your computer and all attached devices from their electrical outlets.
6. Press and hold the power button while the system is unplugged to ground the system board.
7. Remove the computer cover (see Removing and Replacing the Computer Cover
).
CAUTION: Before touching anything inside your computer, ground yourself by touching an unpainted metal
surface, such as the metal at the back of the computer. While you work, periodically touch an unpainted
metal surface to dissipate static electricity, which could harm internal components.
Recommended Tools

Dell Precision T3500 Specifications

General

Tcase	67.9 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	W3550
System bus rate	4.8 GT/s
Processor series	Intel Xeon 3500 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Bloomfield
Processing Die size	263 mm²
Processor frequency	3.06 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.225 V
Number of processors installed	1
CPU multiplier (bus/core ratio)	23
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	731 M
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	24 GB
Display	LCD
Graphics card	FirePro V5900
Dimensions (WxDxH)	172 x 468 x 447 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card manufacturer	AMD
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® X58 Express
Memory slots	-
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	2 x 2 GB
HDD speed	7200 RPM
HDD capacity	500 GB
HDD interface	SATA III
Optical drive type	DVD Super Multi DL
Maximum graphics card memory	2.048 GB
Display diagonal	22 \
Display number of colors	16.78 million colors
PS/2 ports quantity	2
USB 2.0 ports quantity	11
VGA (D-Sub) ports quantity	0
Chassis type	Tower
Product color	Black, Silver
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Operating system installed	Windows XP Professional
Compatible operating systems	Windows 7
Power supply	525 W
Processor ARK ID	39720
Processor package size	42.5 x 45.0 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	468 mm
Width	172 mm
Height	447 mm
Weight	17700 g
