Dell PS Series Installation

Setting Up a PS Series Storage Array
Setting Up a PS Series Storage Array (continued)
5 Connect the Array to the Network
Recommended Configuration: For high performance and availability distribute the connections across multiple network switches. The
switches must be connected with interswitch links that have sufficient bandwidth. See the Installation Guide for more information.
Hardware Installation is Complete!
Your array hardware should now be up and running. If it is not, make sure that you have successfully completed all of the steps described
in this poster.
If you are still experiencing problems, see the Installation Guide for additional installation information.
The Installation Guide also provides technical support and customer service information.
Forlivetechnicalsupport,call1-800-945-3355.
What to do Next
Next, configure the array software. See the Installation Guide for array configuration information.
6 Turn on Power to the Array
Note: Before turning on power, allow enough time for the array to adjust to ambient temperature and humidity (for example, overnight).
Turn on power to both power supply modules (in any order) by pressing (|) on the power switch.
The power switch on each power supply module is located below the power plug.
Note: Batteries will start to charge and some hardware components may start to synchronize when power is turned on. Array LEDs will
indicate this normal activity.
Notes, Cautions, and Warnings
A NOTE indicates important information that helps you make better use
of your system.
A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
A WARNING indicates a potential for property damage, personal
injury, or death.
Printed in U.S.A.
Printed on recycled paper.
DNG36rev.A00
Information in this document is subject to change without notice.
Reproduction in any manner whatsoever without the written
permission of Dell EqualLogic is strictly forbidden.
Dell and EqualLogic are trademarks of Dell Inc.
Copyright2011DellInc.Allrightsreserved.
Switch 0
Switch 1
CM0
CM1
Switch 0 Switch 1
CM0
CM1
10GBASE-T
Optical (SFP+)
DNG36A00
