22 | About your monitor
Environmental characteristics
Description Value
Compliant Standards:
• ENERGY STAR certied Monitor.
• RoHS Compliant.
• BFR/PVC Reduce monitor (The circuit boards are made from BFR/PVC-free
laminates).
• Arsenic-Free glass and Mercury-Free for the panel only.
Temperature:
Operating 0°C to 40°C (32°F to 104°F)
Non-operating –20°C to 60°C (–4°F to 140°F)
Humidity:
Operating 10% to 80% (non-condensing)
Non-operating 5% to 90% (non-condensing)
Altitude:
Operating (maximum) 5,000 m (16,404 ft)
Non-operating (maximum) 12,192 m (40,000 ft)
Thermal dissipation:
S2425H 143.3 BTU/hour (maximum)
49.5 BTU/hour (on mode)
S2725H 153.5 BTU/hour (maximum)
58.0 BTU/hour (on mode)
