About Your Monitor | 11
Monitor Specifications
Flat Panel Specifications
Screen type Active matrix - TFT LCD
Panel type TN
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
684.67 mm (27 inches)
596.74 mm (23.49 inches)
335.66 mm (13.21 inches)
200301.74 mm
2
(310.30 inch
2
)
Pixel pitch 0.2331 mm x 0.2331 mm
Viewing angle 160° (vertical) typical
170° (horizontal) typical
Luminance output 350 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Faceplate coating Anti-Glare with 3H hardness
Backlight LED edgelight system
Response time 3 ms (typical) for NORMAL mode
1 ms (typical) for FAST mode
Color depth 16.7 million colors
Color gamut 72%* (CIE1931)
* Color gamut (typical) is based on CIE1976 (
82%) and CIE1931 (72%) test standards.
Resolution Specifications
Horizontal scan range 69.7 kHz to 250.6 kHz (automatic)
Vertical scan range 30 Hz to 145 Hz (automatic)
Maximum preset resolution 2560 x 1440 at 144 Hz
Model S2716DG/S2716DGR
Model S2716DG/S2716DGR
