Dell S520 - Page 117

Specifications 117
Power Consumption Normal mode: 345 W ± 10% @ 110 Vac
(Network On)
Eco mode: 285 W ± 10% @ 110 Vac (Network
On)
Standby mode: < 0.5 W
Audio 2 speaker x 10 watt RMS
Noise Level Normal mode: 36 dB(A)
Eco mode: 32 dB(A)
Projector Weight 18.74 lbs (8.5 kg)
Dimensions (W x H x D) 14.1 x 9.1 x 14.4 inches (357 x 231 x 367 mm)
Environmental Operating temperature: 5 °C - 40 °C (41 °F-
104 °F)
Humidity: 80% maximum
Storage temperature: 0 ° C to 60 ° C
(32 ° F to 140 ° F)
Humidity: 90% maximum
Shipping temperature: -20 °C to 60 °C
(-4 °F to 140 °F)
Humidity: 90% maximum
I/O Connectors Power: One AC power socket (3-pin - C14
inlet)
VGA input: Two 15-pin D-sub connectors
(Blue), VGA-A and VGA-B, for analog
RGB/Component input signals.
VGA output: One 15-pin D-sub connector
(Black) for VGA-A loop through.
9.1"(231 mm)
14.1"(357 mm)
14.4"(367 mm)
