Specifications 43
NOTE: The lamp life rating for any projector is a measure of
brightness degradation only, and is not a specification for the time it
takes a lamp to fail and cease light output. Lamp life is defined as the
time it takes for more than 50 percent of a lamp sample population to
have brightness decrease by approximately 50 percent of the rated
lumens for the specified lamp. The lamp life rating is not guaranteed
VGA input: One 15-pin D-sub connector (Blue),
VGA In, for analog RGB/Component input
signals.
VGA output: One 15-pin D-sub connector
(Black) for VGA loop through.
Composite Video input: One Yellow RCA jack
for CVBS signal.
HDMI input: Two HDMI connectors for
supporting HDMI 1.4a. specification HDCP
compliant.
Analog Audio input: One 3.5 mm stereo mini
phone jack (Blue)/ One x Audio In RCA pair
(L/R)
Variable audio output: One 3.5 mm stereo mini
phone jack (Green).
Analog Audio input:Two 3.5 mm stereo mini
phone jack(Blue) and two pair of RCA
connector (Red/White)
Microphone : One 3.5 mm stereo mini phone
jack (Pink).
USB (mini USB) port: One mini USB slave for
firmware upgrade/ interactive.
5V/1.8A output: One USB type A 5V DC / 1.8 A
output for support dongle power.
RS232 port: One 9-pin D-sub for RS232
communication.
RJ-45 port: One RJ-45 connector for build-in
for network control.
Touch Unit: one Curtain Module power Jack
Lamp PHILIPS 260 W user-replaceable lamp
Lamp life Normal mode: Up to 3000 hours
Eco mode: Up to 5000 hours
