SS721_Dell_PowerConnect_2800_Series_092010_041212
Product Dell
™
PowerConnect
™
2808 Dell
™
PowerConnect
™
2816 Dell
™
PowerConnect
™
2824 Dell
™
PowerConnect
™
2848
Port configuration
8 10/100/1000BASE-T ports
Auto-negotiation for speed,
duplex mode and flow control
Auto MDI/MDIX mode and
flow control
Integrated Port LEDs
16 10/100/1000BASE-T ports
Auto-negotiation for speed,
duplex mode and flow control
Auto MDI/MDIX mode and flow
control
Integrated Port LEDs
24 10/100/1000BASE-T ports
2 Combo (SFP or 10/100/1000)
Gigabit Ethernet ports
Auto-negotiation for speed,
duplex mode and flow control
Auto MDI/MDIX mode and flow
control
Integrated Port LEDs
48 10/100/1000BASE-T ports
4 Combo (SFP or 10/100/1000)
Gigabit Ethernet ports
Auto-negotiation for speed,
duplex mode and flow control
Auto MDI/MDIX mode and
flow control
Integrated Port LEDs
Performance
Switching capacity 16.0 Gbps
Forwarding Rate 11.9 Mpps
Switching capacity 32.0 Gbps
Forwarding Rate 23.7 Mpps
Switching capacity 48.0 Gbps
Forwarding Rate 35.6 Mpps
Switching capacity 96 Gbps
Forwarding Rate 71.4 Mpps
Management
Web-based management interface;
BootP/DHCP IP address management or Static IP address assignment
RMON statistics
CLI and SNMP Command Subset. (See Users Guides for details)
Class of service
Four priority queues per port
Adjustable WRR and strict priority
Layer 2 IEEE 802.1p tagging and port-based priority
Layer 3 – aware prioritization using DSCP values
Security
Switch access password protection (read-only and read-write access)
Restricted IP address
VLAN
IEEE 802.1Q port-based tagging up to 64 VLANs
Honors all 4096 VLAN tags
Switching features
Industry-standard link aggregation adhering to IEEE 802.3ad standards (static support only, LACP not supported)
Supports 4 link aggregation groups and up to 4 ports per group
Other features
Power Saving Features on Each Port
Lead-Free Construction as per the RoHS Directive
DHCP Server or Client
Availability
Broadcast storm control
Virtual cable tester by Marvell
®
Optical transceiver analysis
Chassis
H x W x L (1.7 x 10.46 x 6.4 in.)
1U, rack-mounting kit included
Unit weight: 5 Lbs.
H x W x L (1.7 x 10.46 x 6.4 in.)
1U, rack-mounting kit included
Unit weight: 6.1 Lbs.
H x W x L(1.7 x 13.0 x 9.1 in.)
1U, rack-mounting kit included
Unit weight: 6.7 Lbs.
H x W x L (1.7 x 17.3 x 10.0 in.)
1U, rack-mounting kit included
Unit weight: 8.6 Lbs.
Optional peripheral products Dell SFP Transceivers (1000-SX and 1000-LX for PowerConnect 2824 and 2848)
© 2011 Dell Inc. All rights reserved. Dell, the DELL logo, the DELL badge and PowerConnect are trademarks of Dell Inc. Other trademarks and trade names may be
used in this document to refer to either the entities claiming the marks and names or their products. Dell disclaims proprietary interest in the marks and names of
others. This document is for informational purposes only. Dell reserves the right to make changes without further notice to the products herein. The content provided
is as-is and without expressed or implied warranties of any kind.
*Select PowerConnect products carry a Lifetime Limited Warranty with Basic Hardware Service (repair or replacement) for life. Repair or replacement does not include
troubleshooting, configuration, or other advanced service provided by Dell ProSupport. For more details see dell.com/warranty.
Learn more at Dell.com/PowerConnect
