Dell U2410 - Back View

Back View

Front View
Control Panel
Label
Description
1-3
Shortcut keys
*The default settings are Preset Modes Select, Brightness/Contrast
Select and Input Source Select.
1
Preset Modes Select
2
Brightness/Contrast Select
3
Input Source Select
4
OSD Menu Select
5
Exit
6
Power Button (with power light indicator)
NOTE:1~5 buttons are capacitive touch buttons, which are activated by placing your finger on the blue LED.
