About Your Monitor | 29
Driver installation
Install the Realtek USB GBE Ethernet Controller Driver available for your system. This
is available for download at https://www.dell.com/support under the “Driver and
download” section.
Network (RJ45) data rate via USB-C max speed is 1000 Mbps.
NOTE: This LAN port is 1000Base-T IEEE 802.3az compliant, supporting
Mac Address (Printed on model label) Pass-thru, Wake-on-LAN (WOL)
from standby mode (S3 only) and PXE Boot function, these 3 features
depend on BIOS setting and OS version.
RJ45 Connector LED Status (U2722DE Only):
Left LED
Right LED
LED Color Description
Right LED Amber or Green Speed indicator:
• Amber On - 100 0 Mbps
• Green On - 100 Mbps
• Off - 10 Mbps
Left LED Green Link / Activity indicator:
• Blinking - Activity on the port.
• Green On - Link is being established.
• Off - Link is not established.
NOTE: RJ45 cable is non in-box standard accessory.
