44 | Setting Up the Monitor
NOTE: Supports the DP MST feature. To make use of this feature, your PC
Graphics Card must be certified to at least DP1.2 with MST option.
NOTE: Remove the rubber plug when using DP out connector.
Connecting the USB-C Cable (A to C)
NOTE: This connection only data is available and no video. Need another
video connection for display.
Connecting the USB-C Cable (C to C)
The USB-C port on your monitor:
• Can be used as USB-C or DisplayPort 1.4, alternatively.
• Supports USB Power Delivery (PD), with profiles up to 90W.
NOTE: Regardless of the power requirement/actual power consumption
of your laptop, or the remaining power runtime in your battery, the Dell
U2722DE monitor is designed to supply power delivery of up to 90 W to
your laptop.
