Dell U2723QE User Manual

About Your Monitor | 11
Back View
7
1
2
3
54 6
Label Description Use
1 VESA mounting holes
(100 mm x 100 mm-behind
attached VESA cover)
Wall mount monitor using VESA-compatible
wall mount kit (100 mm x 100 mm).
2 Regulatory label Lists the regulatory approvals.
3 Stand release button Releases stand from the monitor.
4 Power On/Off button To turn the monitor on or off.
5 Joystick Use it to control the OSD menu.
For more information, see Operating the
Monitor.
6 Mac address, Barcode, serial
number, and Service Tag label
Refer to this label if you need to contact Dell
for technical support. The Service Tag is a
unique alphanumeric identifier that enables
Dell service technicians to identify the
hardware components in your computer and
access warranty information.
7 Cable-management slot Use to organize cables by inserting them
through the slot.

Dell U2723QE Specifications

General

Screen Size	27 inches
Resolution	3840 x 2160 (4K UHD)
Panel Type	IPS Black
Refresh Rate	60 Hz
Aspect Ratio	16:9
Contrast Ratio	2000:1
Response Time	5 ms (gray to gray)
Color Support	1.07 billion colors
Stand Adjustments	Height, Tilt, Swivel, Pivot
Viewing Angle	178° horizontal, 178° vertical
VESA Mount	100 x 100 mm
Brightness	400 cd/m²
Ports	1 x DisplayPort 1.4 (HDCP 2.2), 1 x HDMI 2.0 (HDCP 2.2), 1 x USB-C upstream/DisplayPort 1.4 Alt Mode with Power Delivery (power up to 90W), 4 x USB 3.2 Gen 2 downstream, 1 x USB-C downstream (power up to 15W), 1 x RJ45, 1 x Headphone/microphone combo jack
Color Gamut	98% DCI-P3, 100% sRGB, 100% Rec. 709
Features	ComfortView Plus
Dimensions (with stand)	611.3 mm
