Dell U2723QE User Manual

12 | About Your Monitor
Bottom View
1 4 5 6 7 832
9
10
1312
11
16
1514
Label Description Use
1 Security lock slot Secures monitor with security cable lock (sold separately).
2
Power connector
Connect the power cable.
3
HDMI port
Connect your computer with the HDMI cable.
4
DisplayPort (in)
Connect your computer with the DisplayPort cable.
5
USB-C port
(Video + Data)
Connect to your computer using the USB-C cable.
The USB-C port offer the fastest transfer rate and the
alternate mode with DP 1.4 support the maximum
resolution of 3840 x 2160 at 60Hz PD 20V / 4.5A, 15V /
3A, 9V / 3A, 5V / 3A.
NOTE: USB-C is not supported on Windows versions that
are prior to Windows 10.
6
DisplayPort (out)
DP output for MST (Multi-Stream Transport) capable
monitor. To enable MST, refer to instruction on section
Connecting the Monitor for DP MST Function.
NOTE: Remove the rubber plug when using DP out
connector.

Dell U2723QE Specifications

General

Screen Size	27 inches
Resolution	3840 x 2160 (4K UHD)
Panel Type	IPS Black
Refresh Rate	60 Hz
Aspect Ratio	16:9
Contrast Ratio	2000:1
Response Time	5 ms (gray to gray)
Color Support	1.07 billion colors
Stand Adjustments	Height, Tilt, Swivel, Pivot
Viewing Angle	178° horizontal, 178° vertical
VESA Mount	100 x 100 mm
Brightness	400 cd/m²
Ports	1 x DisplayPort 1.4 (HDCP 2.2), 1 x HDMI 2.0 (HDCP 2.2), 1 x USB-C upstream/DisplayPort 1.4 Alt Mode with Power Delivery (power up to 90W), 4 x USB 3.2 Gen 2 downstream, 1 x USB-C downstream (power up to 15W), 1 x RJ45, 1 x Headphone/microphone combo jack
Color Gamut	98% DCI-P3, 100% sRGB, 100% Rec. 709
Features	ComfortView Plus
Dimensions (with stand)	611.3 mm
