Expansion Bus
USB 480 Mbps
Cards
PCIe x16 one full-height card
PCIe x1 up to three full-height cards
Drives
Vostro 260 Vostro 260S
Externally accessible:
5.25 inch drive bays two one
Internally accessible:
3.5 inch drive bays two one
External Connectors
Audio:
Back panel three connectors
Front Panel two front-panel connectors for headphone
and microphone
Network one RJ45 connector
USB:
Front panel
• one USB 2.0 connector
• one powered USB 2.0 connector
Back panel six USB 2.0 connectors
Video
• one 15-hole VGA connector
• one 19-pin HDMI connector
Control Lights And Diagnostic Lights
power button light white light — solid white light indicates
power-on state.
47
