Table 6. Storage specifications
Form factor Interface type Capacity
2.5-in. 5400 rpm, hard drive SATA 1 TB
2.5-in. 7200 rpm, hard drive SATA 500 GB
M.2 2230/2280 solid-state drive PCIe NVMe 3x4 Upto 512 GB
M.2 2280 Intel Optane Memory (10th Gen Processors) PCIe NVMe 3x4 512 GB
NOTE: Intel Celeron 5000 Series Processors would support PCIe Gen 2 speeds only.
Intel UHD Graphics
Table 7. Intel UHD Graphics specifications
Intel UHD Graphics
Bus Type Integrated
Memory Type UMA
Graphics Level i3/i5/i7: GT2 (UHD)
Estimated Maximum Power Consumption (TDP) 15 W (included in the CPU power)
Overlay Planes Yes
Operating Systems Graphics/ Video API Support DirectX 12, OpenGL (4.5 from Intel CML POR)
Maximum Vertical Refresh Rate
● HDMI 1.4: 4096 x 2160 @ 60 Hz, 24bpp, Via optional USB
Type-C to HDMI dongle
● Max Digital: (DP 1.2 over Type-C Port) 4096 x 2304 @ 60
Hz, 24bpp
Number of display supported
Up to three displays supported via DisplayPort Multi-
Streaming Technology (MST)
Multiple Display Support
Via Type-C: HDMI 1.4 (via optional USB-C cable to HDMI
cable);
DisplayPort 1.2 (via optional USB-C cable or USB-C to DP
cable);
External Connectors
● USB Type–C port
● HDMI 1.4 port
Ports and connectors
Table 8. External ports and connectors
Description Values
External:
Network
One Flip-down RJ 45 10/100/1000 Mbps
USB
● One USB 3.2 Gen 1 Type-C port with DisplayPort alt
mode/Power Delivery
● One USB 3.2 Gen 1 Type-A port with PowerShare
Technical specifications 15
