Dell Vostro 3000 - Media-Card Reader; Power Adapter

Table 17. WWAN module
Feature Specifications
Model number Dell DW5820e Intel 7360 LTE-A
Host interface M.2 3042 form factor
Network standard LTE FDD/TDD, WCDMA/HSPA+, GNSS/Beidou
Transfer rate Up to 450 Mbps DL/50 Mbps UL (Cat 9)
Operating Frequency Bands (1,2,3,4,5,7,8,11,12,13,17,18,19,20,21,26,28,29,30,38,39,40,41,66
), HSPA+ (1, 2, 4,5, 8)
Data Rate
● LTE FDD: 450 Mbps DL/50 Mbps UL (Cat 9)
● LTE TDD: 347 Mbps DL/30 Mbps UL (Cat 9)
● UMTS/HSPA+: UMTS 384 kbps DL/384 kbps UL
Power supply DC 3.135 V to 4.4 V, Typical 3.3 V
Antenna Diversity Supported
Radio On/Off Supported
Wake On Wireless Supported
Temperature
● Normal operating temperature: -10°C to + 55°C
● Extended Operating temperature: -20°C to +65°C
NOTE: Variation in temperature can affect the
performance of the WWAN card.
Antenna connector
● WWAN Main Antenna X 1
● WWAN Diversity Antenna X 1
Media-card reader
Table 18. Media-card reader specifications
Description Values
Type
One Micro SD 3.0 card
Cards supported
● Micro Secure Digital (mSD)
● Micro Secure Digital High Capacity(mSDHC)
● Micro Secure Digital Extended Capacity(mSDXC)
Power adapter
Table 19. Power adapter specifications
Description Values
Type
45W 65W 65W Type-C (Optional)
Connector dimensions:
2.9 mm x 4.5 mm 2.9 mm x 4.5 mm 48.26 mm x 129.54 mm x
215.9 mm
Input voltage
100 VAC x 240 VAC 100 VAC x 240 VAC 100 VAC x 240 VAC
Input frequency
50 Hz x 60 Hz 50 Hz x 60 Hz 50 Hz x 60 Hz
Technical specifications 19
