Dell Vostro 3070 - Installing the memory module; Removing power supply unit

a Push the memory module retention tabs on both sides of the memory module.
b Lift the memory module from the memory module connector on the system board.
Identifier GUID-13CEBF02-3193-4AA6-9A16-9881311B3E56
Status Released
Installing the memory module
1 Align the notch on the memory module with the tab on the memory module connector.
2 Press the memory module until the memory module retention tabs click into place.
3 Install the:
a Cover
4 Follow the procedure in After working inside your computer.
Identifier GUID-F8164337-4D5F-47F7-AEB2-E426D33BEB4B
Status Released
Power supply unit
Identifier GUID-316844EC-0A6A-4402-865F-83B2C9A7809B
Status Released
Removing power supply unit
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Cover
b Cooling shroud
3 Removing the Power supply unit (PSU):
a Disconnect the PSU cables from the connectors on the system board.
28
Removing and installing components
