Identifier GUID-6D80D2E4-6FDC-4158-B13A-DD044EFA533C
Status Released
Processor
Identifier GUID-85A717C7-4E9B-4EEB-89C7-34E375417515
Status Released
Removing the processor
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Cover
b Cooling shroud
c Heat sink assembly
3 To remove the processor:
a Press the release lever down and then move it outward to release it from the retention hook [1].
CAUTION: The processor socket pins are fragile and can be permanently damaged. Be careful not to bend the pins in
the processor socket when removing the processor out of the socket.
b Lift the processor cover and remove the processor from the socket [2, 3].
Removing and installing components
47
