Dell Vostro 3070 - Cooling Shroud; Removing the Cooling Shroud

Identifier GUID-60A52EA6-2990-49F4-9800-B9A7C0A5D6BC
Status Released
Cooling shroud
Identifier GUID-0F037793-C117-424A-9885-5D588863EDF6
Status Released
Removing the cooling shroud
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Cover
3 To remove the cooling shroud:
a Pry and release the tabs that secure the cooling shroud to the process fan [1, 2, 3].
b Lift the cooling shroud away from the computer.
Removing and installing components
37
