Removing The Coin-Cell Battery
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Remove the expansion card.
4. Press the release latch away from the battery and pop up the battery from the socket on the system board.
Figure 21.
Installing The Coin-Cell Battery
1. Insert the coin-cell battery into the slot.
2. Install the expansion card.
3. Install the cover.
4. Follow the procedures in After Working Inside Your Computer.
