 Internal Card With Bluetooth
®
Wireless Technology
Dell™Vostro™A840/A860ServiceManual
Removing the Bluetooth®Card
Replacing the Bluetooth®Card

Removing the Bluetooth®Card

1. Follow the instructions in "BeforeYouBegin"onpage9.

2. Remove the palm rest (see Palm Rest).

3. Remove the bluetooth card cable connector from the system board.

4. Gently lift the bluetooth card from the bluetooth card compartment on the computer base.
Replacing the Bluetooth®Card

1. Replace the bluetooth card in the compartment in the computer base.

2. Replace the bluetooth cable connector to the system board.

3. Follow the instructions in Replacing the Palm Rest.

4. Slide the battery into the battery bay, until it clicks in place.
Back to Contents Page

CAUTION: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as the back panel) on the computer.
1
bluetooth card cable
2
bluetooth card
3
bluetooth card compartment
4
bluetooth card cable connector
