8 About Your TV
www.dell.com | support.dell.com
FILE LOCATION: C:\Documents and Settings\solinak\Ƈ¦±\OM update\ch1e.fm
DELL CONFIDENTIAL – PRELIMINARY 10/8/04 – FOR PROOF ONLY
13 Composite video and
audio-out connectors
Connect a device such as a VCR if you have connected an antenna or
cable TV through the ANT/Cable connector
14 Subwoofer audio out Connect an optional powered subwoofer to the TV
15 Optical digital out (SPDIF)
(for W4200HD only)
Connect an audio decoder or audio/video receiver
16 Coaxial digital audio out
(for W4200HD only)
Connect an audio decoder or audio/video receiver when using a Digital
TV (ATSC connector)
17 ATSC connector
(for W4200HD only)
Connect an antenna for the digital tuner when using Digital TV
(ATSC connector)
18 NTSC connector Connect an antenna or a cable TV box
19 Speaker out connectors Connect speakers
20 Power connector Connect your power cord
