Table 8. Docking Specifications (continued)
Features Specifications
● DisplayPort++ 1.4 x2
Network Port
● Gigabit Ethernet (RJ-45) x1
● Support Wake On LAN from S3, S4, or S5 sleep state with select Dell systems.
See platform setup guide for more details.
● Support MAC Address Pass-Through with select Dell systems. See platform
setup guide for more details.
USB Ports
● Front USB 3.1 Gen1 x1: Dell PowerShare BC1.2; 2 A @ 5 V (max 10 W)
● Front USB 3.1 Gen1/Gen2 Type-C: 1.5 A @ 5 V (max 7.5 W)
● Rear USB 3.1 Gen1 x2: 0.9 A @ 5 V (max 4.5 W)
● Rear USB 3.1 Gen1/Gen2 Type-C with DisplayPort 1.4 x1: 3 A @ 5 V (max 15 W)
DC-in Port 7.4 mm DC-in port x1
USB Type-C cable length 0.8 m
Power delivery Dell systems
● 210 W to Dell Precision mobile workstations 7000 series with 240 W AC-adapter
● 130 W to Dell systems (single cable plugged in) with 240 W AC-adapter
Non-Dell systems
● 90 W support for USB Power Delivery 3.0 (single cable plugged in).
Button
● Sleep/Wakeup/Power button
Table 9. Environment specifications
Feature Specifications
Temperature range Operating: 0°C–35°C (32°F–95°F)
Non-operating:
● Storage: -20°C to 60°C (-4°F to 140°F)
● Shipping: -20°C to 60°C (-4°F to 140°F)
Relative humidity Operating: 10% to 80% (non-condensing)
Non-operating:
● Storage: 5% to 90% (non-condensing)
● Shipping: 5% to 90% (non-condensing)
Dimension 205 mm x 90 mm x 29 mm
Weight 450 g (0.99 lb)
VESA Mounting options Yes—using Dell Docking station mounting kit
Input/Output (I/O) Connectors
The Dell Performance Docking Station WD19DCS has the following I/O connectors:
Table 10. I/O connectors
Ports Connectors
Video Ports
● DisplayPort++ 1.4 x2
● USB 3.1 Gen1/Gen2 with DisplayPort 1.4 or HDMI2.0 x1
26 Technical specifications
