book.book Page 67 Monday, June 25, 2012 11:55 AM
3
Procedure
1 Remove the screws that secure the display hinges to the palm-rest assembly.
2 Open the palm-rest assembly as far as possible.
1 screws (6) 2 display hinges (2)
3 palm-rest assembly
Slide and remove the tabs on the palm-rest assembly from the display hinges.
1 palm-rest assembly 2 tabs (2)
3 display
Removing the Display | 67
