28 About Your Computer
DELL WI -FI CATCHER™ NETWORK LOCATOR — Push this button to scan
specifically for wireless networks in your vicinity.
The Wi-Fi Catcher Network Locator has an LED that operates as follows:
– Flashing blue: Searching for networks
– Solid blue: Strong network found
– Solid yellow:
Weak network found
– Off: No signal found
NOTE: The Dell Wi-Fi Catcher Network Locator light appears only when the
computer is turned off and wireless networking is activated in the system setup
program.
USB CONNECTORS
SECURITY CABLE SLOT — Lets you attach a commercially available antitheft device
to the computer (see "Security Cable Lock" on page 103).
Back View
AIR VENTS — The computer uses an internal fan to create airflow through the vents,
which prevents the computer from overheating.
Connect USB devices, such as a mouse, keyboard, or printer.
1 air vents 2 AC adapter connector
3 USB connector 4 network connector (RJ-45)
1 432
