DELLA Versa TL Series - Product Specification

9
v.20240726U
Product Specication (Indoor Unit)
048-TL-9K2V-19S-IN 048-TL-12K2V-19S-IN 048-TL-18K2V-19S-IN 048-TL-24K2V-19S
Power Supply 208 V - 230 V / 60 Hz / 1P 208 V - 230 V / 60 Hz / 1P 208 V - 230 V / 60 Hz / 1P 208 V - 230 V / 60 Hz / 1P
Rated Cooling Capacity (Btu / h) 9000 12000 18000 24000
Rated Heating Capacity (Btu / h) 10000 12200 19600 24400
Noise Level 27 - 41 dBA 27 - 42 dBA 32 - 50 dBA 35 - 51 dBA
Dimension
31.92" x 11.49" x 8.07"
811 mm x 292 mm x 205 mm
31.92" x 11.49" x 8.07"
811 mm x 292 mm x 205 mm
39.76" x 12.40" x 8.66"
1010 mm x 315 mm x 220 mm
46.93" x 14.17" x 10.23"
1192 mm x 360 mm x 260 mm
Net Weight 19.8 lb / 9 kg 19.8 lb / 9 kg 28.7 lb / 13 kg 36.4 lb / 16.5 kg
Suitable Area Up to 400 sq. ft Up to 550 sq. ft Up to 1000 sq. ft Up to 1500 sq. ft
Moisture Removal (per hour) 2.3 pints / 1.1 L 3.4 pints / 1.6 L 4.6 pints / 2.2 L 5.5 pints / 2.6 L
