Fig. 5.5
To ensure internal ventilation, aeration
channels must be provided as illustrated
in the figures 5.4 and 5.5.
The walls surrounding the oven must
be made of heat-resistant material.
Taking care NOT to lift the oven by the
door handle.
Fig. 5.6
IMPORTANT:
To avoid damage to the lower trim
please note the following instructions.
The lower trim is designed to allow for
good air circulation and the correct open-
ing of the oven door.
To ensure the trim is not damaged due to
the appliance being placed on the floor,
the appliance should be suitably support-
ed as in above illustrations.
After installation the appliance door
should be slowly opened to ensure no
damage has occurred.
No responsibility for lower trim dam-
age will be accepted if these instruc-
tions have not been followed.
