GB
17
The instructions below will enable you to prepare your air conditioner for operation as efficiently
as possible.
Before use, make sure the air intake and outlet grilles are unobstructed.
INSTALLATION
The sheath connecting the external and inter-
nal units can pass:
a) through a window or door left ajar (fig. A).
A
Preparing for use
USING THE QUICK-FIT COUPLINGS (some
models only)
In addition to the methods described above,
the sheath connecting the external and inter-
nal units can also pass through a hole with a
diameter of about 6 cm cut in an outside wall
(fig C) proceeding as follows:
b) Through a small hole (5.5 cm x 2.5 cm) cut
in the bottom part of a door or in a win-
dow frame, protecting the sheath by
using the frame provided (fig. B).
B
ø6
cm
30
C
Turn the appliance off and unplug from the
mains.
Wait about 30 minutes before following the
instructions below:
1) Remove the screws and take off the cover
of the quick-fit coupling compartment.
2) Press the tab to disconnect the electrical
connection.
ELECTRICAL CONNECTIONS
Before plugging the appliance into the mains socket, check that:
• the mains power supply corresponds to the value indicated on the rating plate on the back of the appliance;
• the mains socket and electrical circuit are adequate for the appliance;
• the mains socket matches the plug. If this is not the case, have the plug replaced;
• the mains socket is adequately earthed.
• the mains socket is adequately earthed. Failure to follow these important safety instructions absolves the
manufacturer of all liability.
The power cable must be replaced by a qualified professional only.

DeLonghi CF 1130 Specifications

Internal Unit Dimensions

width	480 mm
height	840 mm
depth	300 mm
weight	44 kg

External Unit Dimensions

width	450 mm
height	450 mm
depth	300 mm
weight	18 kg

Operating Environment

room temperature for air conditioning	21 - 32°C
