DeLonghi CF 1130 User Manual

GB
23
Using the remote control unit
REMOTE CONTROL DEVICE
• Point the remote control at the receiver on
the air-conditioner.
• The remote control should be handled
with extreme care and respect. Do not
drop it, expose it to direct sunlight, or
leave it near sources of heat.
DESCRIPTION OF THE REMOTE CONTROL
17) "ON/OFF" button
18) "MODE" button
19) Programmed operation temperature
increase button
20) Programmed operation temperature
decrease button
21) "TIMER" button
22) Fan speed selection button
(HIGH/MED/LOW)
NB. All functions can be selected from either
the control panel or the remote control
device.
Replacing the batteries
• Remove the cover on the rear of the
remote control;
• Replace the old batteries with two new
LR03 “AAA” 1.5V batteries, inserting them
correctly (see the instructions inside the
battery compartment);
• Replace the cover.
If the remote control unit is replaced or
discarded, the batteries must be removed
and disposed of in accordance with current
legislation as they are harmful to the envi-
ronment.
TURNING THE APPLIANCE ON
Plug the appliance into the mains.
Press the ON/OFF button (17) (when turned on, the air conditioner starts operating in the same
mode as when it was turned off).
Press the MODE button (18) to select the required mode
COOLING
DEHUMIDIFYING
FAN ONLY
On the control panel, the light corresponding to the selected mode comes on.
For air conditioning/dehumidifying/fan only settings and programming the timer, see page 21-22.
19
18
20
22
19
21

DeLonghi CF 1130 Specifications

Internal Unit Dimensions

width	480 mm
height	840 mm
depth	300 mm
weight	44 kg

External Unit Dimensions

width	450 mm
height	450 mm
depth	300 mm
weight	18 kg

Operating Environment

room temperature for air conditioning	21 - 32°C
