DeLonghi CF 1130 User Manual

21
GB
Operation
TURNING THE APPLIANCE ON
Plug the appliance into the mains.
Press the ON/OFF button (A) (when turned on, the air conditioner
starts operating in the same mode as when it was turned off).
The display shows the room temperature.
Press the MODE button (B) until the indicator light corresponding
to the required mode lights up:
Light (O): air-conditioning mode
Light (N): fan mode
Light (P): dehumidifying mode
AIR-CONDITIONING MODE
Ideal for hot humid weather when you need to cool and dehu-
midify the room.
To set operation of the appliance correctly, press the + (E) or - (F)
buttons until the desired temperature is displayed.
Then select the fan speed by pressing the FAN button (C) until the
indicator light corresponding to the required fan speed lights up:
HIGH: the air conditioner operates at maximum to reach the
required temperature as rapidly as possible
MED reduces noise levels but still maintains a good level of
comfort
LOW: for silent operation
The most suitable temperature for the room during the summer
varies from 24 to 27°C.
You are recommended, however, not to set a temperature much
below the outdoor temperature.

DeLonghi CF 1130 Specifications

Internal Unit Dimensions

width	480 mm
height	840 mm
depth	300 mm
weight	44 kg

External Unit Dimensions

width	450 mm
height	450 mm
depth	300 mm
weight	18 kg

Operating Environment

room temperature for air conditioning	21 - 32°C
