DeLonghi CF 1130 User Manual

20
Control panel
DESCRIPTION OF THE CONTROL PANEL
A ON/OFF button
B MODE selection button
Air conditioning, dehumidifying, fan.
C Fan speed selection button (HIGH/MED/LOW)
D Timer button
E Programmed operation increase temperature/time button
F Programmed operation decrease temperature/time button
G Display
Displays the temperature values set and the programmed operating time
H Timer in operation indicator light
I/L/M Fan speed lights
N Fan mode light
O Air-conditioning mode light
P Dehumidifying mode light
Q Alarm light
BA
H
C
N
D
E
THE CONTROL PANEL
F
I
L
M
P
O
Q
G

DeLonghi CF 1130 Specifications

Internal Unit Dimensions

width	480 mm
height	840 mm
depth	300 mm
weight	44 kg

External Unit Dimensions

width	450 mm
height	450 mm
depth	300 mm
weight	18 kg

Operating Environment

room temperature for air conditioning	21 - 32°C
