36
1
2
M
M
M
2
1
click
click
REPLACE THE GLASS RETAINER
1. Position the glass retainer, as shown in the gure 32. It should sit on the bottom edge
of the outer glass. Check that the clamps “M
”
are not deformed or damaged.
2. Gently push the glass retainer back into place. You should be able to hear the tabs on
both sides click as they lock the glass retainer in.
Important!
Make sure the glass retainer is correctly and rmly in place and that the glass pane
is secure.
Figure 32
