19
L
Fig. 5.7
Fig. 5.8
H
Fig. 5.9
REMOVING THE OVEN DOORS
To facilitate oven cleaning, it is possible to remove the door.
Please follow the instructions carefully:
– Open the door completely.
– Push down the lever “L” and, keeping it in this position, slowly close the door in
order to block the hinge (fig. 5.7).
– Grip the door (as indicated in fig. 5.8) and, while closing it, release the two hinges as
shown in fig. 5.9.
– Rest the door on a soft surface.
DOOR ASSEMBLY
– Grip the door with your hands placed near the hinges and raise the levers “H” with
your forefingers (fig. 5.9)
– Insert the hinges in their position until levers “H” are hooked.
– Open the door completely to obtain the release of levers “L”.
OVEN DOORS
The internal glass of the oven doors can be easily removed for cleaning by unscrewing
the two fixing screws (figs. 5.5 - 5.6).
Fig. 5.5
Fig. 5.6
Do not store flammable material in the ovens.
