DeLonghi DMFPSII - Removing Oven Door

Fig. 4.4
B
A
C
REMOVING THE OVEN
DOOR
The oven door can easily be removed
as follows:
– Open the door to the full extent (fig.
31a).
– Open the lever “A” completely on the
left and right hinges (fig. 31b).
– Hold the door as shown in fig. 31.
– Gently close the door (fig. 31) until
left and right hinge levers “A” are
hooked to part “B” of the door (fig.
31b)
– Withdraw the hinge hooks from their
location following arrow “C” (fig.
31d).
– Rest the door on a soft surface.
– To replace the door, repeat the above
steps in reverse order.
Figure 31
Figure 31a
Figure 31b
Figure 31c
Figure 31d
34
