DeLonghi EC820.B - Description of the appliance and control panel

3
Control Panel
Cup shelf
General switch
ON/OFF
Power supply
cable
connector
Control panel (see
description below)
Steam/
hot water
selector
Cup tray
Drip tray
Hot water/
steam nozzle
Cappuccino
nozzle
Water tank with
water lter seat
Boiler outlet/
Infusion assembly
Water tank seat
Water tank lid
ON/Stand-by Button
Indicator for
drip tray
maximum
water level
Function selector
Stand-by/energy save light
OK coee/
hot water light
Coee delivery
“STOP”/hot water function position
Steam function
OK steam light
Water low
level indicator
Description of the appliance and control panel
