DeLonghi EO 3850.A - Chapter 1 General; Description of the Oven and Accessories

17
A Top heating element
B Oven light
C Turnspit mount (if fitted)
D Thermostat knob
E Thermostat pilot light
F On/off and timer knob
G Function selector knob
H Control panel
1.1 - DESCRIPTION OF THE OVEN AND THE ACCESSORIES
CHAPTER 1 – GENERAL
I Bottom heating element
L Crumb tray
M Dripping pan
N Wire rack
O Spit (if supplied)
P Spit supports (if supplied)
Q Lasagne pan (if supplied)
Guide 1
Guide 2
Guide 3
Guide for crumb tray only
To ensure the correct operation of the appliance and achieve
excellent results when cooking, ALWAYS place the crumb tray (L)
in position at the bottom of the oven.
CRUMB TRAY (L)
