• If the windows are large, use additional window bracket
(B4) to cover your window aperture, extending it to the
required length, then blocking it with the locking wing nut
supplied (g. 3).
max 33ft~
12
3
3
8
9
9
10
6
4
Click
5
• Insert and lock the accessory for window bracket (B1) al-
ready assembled to the air exhaust hose, into the slot of the
window bracket (g. 4).
max 33ft~
12
3
3
8
9
9
10
6
4
Click
5
• In order to facilitate the tting of the air exhaust hose (B2)
in the relevant housing located on the rear side of the ap-
pliance, position the hose adapter‘s tabs (B3) in a vertical
axis as shown in g. 5 .
max 33ft~
12
3
3
8
9
9
10
6
4
Click
5
• Fit the air exhaust hose (B2) in the relevant housing located
on the rear side of the appliance (g . 6).
max 33ft~
12
3
3
8
9
9
10
6
4
Click
5
SLIDING WINDOWS
• Thanks to the locking wing nut, it’s possible to use the win-
dow bracket also for sliding windows. Position the hole of the
bracket so to allow a correct installation of the exhaust hose .
OPERATING FROM THE CONTROL PANEL
C1
C15
C13
C12
C11
C10
C9
C8
C7
C6
C16C17
C3
C4
C2
C5
C14
DESCRIPTION OF THE CONTROL PANEL (C)
C1. ON/STAND-BY (on/o) key
C2. Function selection key MODE (air conditioning, dehumidi-
fying, fan)
C3. Increase key
C4. Decrease key
C5. Fan speed selection key (MIN/MED/MAX/AUTO)
C6. Air conditioning symbol
C7. Dehumidifying symbol
C8. Fan symbol
C9. ECO REAL FEEL symbol/status indicator
C10. Swing symbol
C11. Fan speed indicator
C12. ARCTIC WHISPER EXTREME symbol
