REPLACING THE MIDDLE
AND INNER PANES OF
GLASS
1. Make sure the door is locked open
(see fig. 34).
2. Replace the middle pane:
•Check that the four rubber pads
are in place (M in fig. 40).
•Check that you are holding the
pane the correct way. You should
be able to read the wording on it
as it faces you.
•Gently insert the top edge of the
pane into the top clamps (arrow 1
in fig. 41), then lower the pane
and insert the bottom edge into
the bottom clamps (arrow 2 in fig.
41); and then slide the pane into
position (fig. 42).
M
1
2
1
Figure 40
Figure 41
Figure 42
M
