2. MACHINE OVERVIEW
1 Cold water icon
2 XL volume function
3 ON/OFF icon /
Descalingsignal/
Error signal
4 Used capsule icon
5 Hot water icon
6 Touch volume selector / Bar display
7 Capsule holder
8 Rinsing tool
9 Water tank
10 Injector
11 Dripgrid
12 Driptray
13 Cleaning needle
14 Injectortool
15 Capsule bin
IE / UK
220-240 V, 50-60 Hz, max. 1500 W
TECHNICAL DATA
ECONOMY MODE
After 5 minutes of non-usage
max. 15 bar
1 L
~3.5 kg
5-45 °C
41-113 °F
A= 27.4 cm
B = 32.1 cm
C = 33.2 cm
