DeLonghi PACAN285 - Wall Flange and Hose Connection; Air Conditioning Without Installation

6
4) Fit the wall ange 12 into the hole.
5) Screw the hose adaptor 14 to the hose’s end 13 (g. A).
6) Fit the air exhaust hose in the housing at the back of the
appliance as shown in gure A.
7) Screw the wall mounting accessory 15 into the hose 13
(g. D) and t it into the wall ange 12 as shown in g. E.
When the hose 13 is not tted, the hole can be closed with the
ange cap 12.
Air conditioning without installation
You can also set-up in a double-hung window:
1) Place the bracket in the window sill, extend the bracket
fully within the window frame, x the bracket by using the
pin then lower the window onto the bracket. (Should the
window bracket be too large for the window. The plastic
can be cut with a saw by a qualied professional).
2) Fit the air exhaust hose in the housing at the back of the
appliance. Insert it as shown in g. A.
3) Screw the window outlet 17 to the other end of the
exhaust hose (see g. F).
4) Insert the window outlet end of the exhaust hose into the
slot of the window bracket (g. G).
Other set-up methods:
• Thanks to the locking pins, it’s possible to use the window
bracket also for sliding windows. Position the hole of the
bracket so to allow a correct installation of the exhaust
hose (see g. H).
• If you have a casement window f ollow steps 2 & 3 and
place the window outlet outside the window to exhaust
the hot air (g. I).
2
D
MAX100 cm
MAX 39 inches
MIN 35 cm
MIN 14 inches
E
Note:
• As special tools are required for installation, we
suggest you have the appliance installed by specialized
personnel.
• Keep the air hoses as short and free of curves as possible
to avoid constrictions.
G
H
I
2
1
2
F
