DESCRIPTION OF THE REMOTE CONTROL
1 Air conditioning symbol
2 Dehumidifying symbol
3 Fan symbol
4 Heating symbol
5 Smart symbol
6 Signal transmission
7 Selected temperature scale indica-
tor
8 Relative humidity indicator
9 SLEEP symbol
10 AUTOFAN indicator
11 Fan speed indicator
12 Clock
13 Timer ON symbol
14 Timer OFF symbol
15 MODE button (selects the modes)
16 ON/Stand-by button
17 FAN button
18 Increase (+) and decrease (-) tem-
perature button
19 Reset button (resets the factory
default settings)
20 Timer ON button
21 SET button
22 Timer OFF button
23 SWING button
24 SLEEP button
25 °C or °F selection button
USING THE REMOTE CONTROL
Point the remote control at the receiver on
the appliance. The remote control must be
no more than 7 metres away from the
appliance (without obstacles between the
remote control and the receiver).
The remote control must be handled with
extreme care. Do not drop it or expose it to
direct sunlight or sources of heat.
