Assembly Manual
4 Way GT 280 Sealed Connection System
GT 2.8 Terminal System (Sealed)
© Delphi Corporation. All Rights Reserved
www.delphi.com
Assembly Manual - 33278895
6
Pictures used in this Assembly Manual and original parts may differ in some
details. These differences have no influence on the assembly process.
ASSEMBLY
FEMALE CONNECTOR
QUANTITY COMPONENTS
1 PLR
1 CONNECTOR SEAL
1 FEMALE CONNECTOR
1
CPA *
LIST OF COMPONENTS & EXPLODED VIEW
CONNECTOR
SEAL
CPA *
PLR
* OPTIONAL COMPONENT
