Assembly
Manual
4 W
ay GT 280
Sealed C
onnection Syst
em
GT 2.8 T
erminal Sy
stem
(Sealed)
© Delphi
Corporation.
All Rights Reserved
ww
w.delphi.com
Assembly M
anual -
33278895
7
ST
EP
1a
–
Insert Co
nnector Seal
ST
EP
1b
–
Insert Connector Seal
A
SSEMBL
Y
CONNECT
OR SEAL
A
SSE
MBLED
VERIFY
THE ORIENT
A
TION OF THE SEA
L A
ND
INSERT IT INT
O THE CONNEC
TOR
IMPORT
A
NT!
VERIFY
THA
T
CONNECT
OR SEA
L IS NOT BU
NCHED OR ROLLED
DURING TH
E INSERTION
6
8
Table of Contents
Table of Contents
4
Car Assembly Section
5
Assembly of the Connection System
17
List of Components & Exploded View
18
Model
19
Step 1 - Identify Index Features
20
Step 2 - Align Index Features and Mate Female Assembly and Mating Part Together
20
Step 3 - Lock CPA to Full - Stage Position (Optional Component)
21
Connection System - Completed Assembly
22
Disassembly of the Connection System
23
Step 1 - Move CPA to Pre-Stage Position (Optional Component)
24
Step 2 - Disconnect
25
Connection System - Completed Disassembly
25
Repair / Replacement Section
26
Female Connector Sub Components
26
PLR Replacement - Step 1 (Remove PLR)
27
Step 2 (Install PLR)
28
TERMINAL F 2.8 Replacement - Step 1 (Remove Terminal)
28
Step 2 (Insert Terminal)
30
Recommended Repair Tools
31
Revisions
32
