Chapter 5 Trial Run and Tuning Procedure
Please refer to the following table for 64 groups of position commands and position
command selection from POS0 to POS5.
Position
Command
POS5 POS4 POS3 POS2 POS1 POS0 CTRG Parameters
P6-00
P1 0 0 0 0 0 0
P6-01
P6-02
P2 0 0 0 0 0 1
P6-03
~ ~
P6-98
P50 1 1 0 0 1 0
P6-99
P7-00
P51 1 1 0 0 1 1
P7-01
~ ~
P7-26
P64 1 1 1 1 1 1
P7-27
0: indicates OFF (Normally Open); 1: indicates ON (Normally Closed)
The users can set the value of these 64 groups of commands (P6-00 ~ P7-27) freely. The
command can be absolute position command as well.
