Chapter 2 Installation and Storage
2.6 EMI Filter Selection
AC Servo Drive - EMI Filter Cross Reference
220V Series
Item Power Servo Drive Model Recommended EMI Filter FootPrint
1 100W
ASD-A2-0121-ï‚£
08TDT1W4S N
2 200W
ASD-A2-0221-ï‚£
08TDT1W4S N
3 400W
ASD-A2-0421-ï‚£
08TDT1W4S N
4 750W
ASD-A2-0721-ï‚£
11TDT1W4S N
5 1000W
ASD-A2-1021-ï‚£
11TDT1W4S N
6 1500W
ASD-A2-1521-ï‚£
11TDT1W4S N
7 2000W
ASD-A2-2023-ï‚£
20TDT1W4D N
8 3000W
ASD-A2-3023-ï‚£
20TDT1W4D N
9 4500W
ASD-A2-4523-ï‚£
20TDT1W4D N
10 5500W
ASD-A2-5523-ï‚£
RF075M43BA Y
11 7500W
ASD-A2-7523-ï‚£
RF075M43BA Y
400V Series
Item Power Servo Drive Model Recommended EMI Filter FootPrint
1 750W
ASD-A2-0743-ï‚£
11TDT1W4S N
2 1000W
ASD-A2-1043-ï‚£
11TDT1W4S N
3 1500W
ASD-A2-1543-ï‚£
11TDT1W4S N
4 2000W
ASD-A2-2043-ï‚£
20TDT1W4D N
5 3000W
ASD-A2-3043-ï‚£
20TDT1W4D N
6 4500W
ASD-A2-4543-ï‚£
20TDT1W4D N
7 5500W
ASD-A2-5543-ï‚£
RF075M43BA Y
8 7500W
ASD-A2-7543-ï‚£
RF075M43BA Y
NOTE
The boxes (ï‚£) in the model names are for optional configurations. (Please refer to section 1.2 for
model explanation.)
