Delta Electronics ASDA-A2 Series User Manual

Chapter 2 Installation and Storage
2-18 Revision January 2011
Allowable frequency when the servo motor runs without load (times/min)
and uses a built-in regenerative resistor
600W 750W 900W 1.0kW 1.5kW 2.0kW 2.0kW 3.0kW 4.5kW 5.5kW 7.5kW Motor Capacity
Servo Motor
06 07 09 10 15 20 20 30 45 55 75
ECMAF
- - - - - - - 11 8 - -
ECMAG
42 - 31 - - - - - - - -
ECMAJ
- 537 - - - - - - - - -
ECMAK
- - - 162
122 - - - - - -
ECMAL
- - - - - - - - - - -
When the servo motor runs with load, the allowable frequency will change according to
the changes of the load inertia and rotation speed. Use the following equation to calculate
the allowable frequency.
Allowable frequency =
Allowable frequency when servo motor run without load
m + 1
x
Rated s peed
Operating speed
times
min.
2
m = load/motor inertia ratio
The users can select the adequate external regenerative resistors according to the
allowable frequency by referring to the table below:
Allowable frequency when the servo motor run without load (times/min)
and uses external regenerative resistor
ECMAC
100W 200W
400W
(F60)
400W
(F80)
750W 1.0kW 2.0kW
Motor Capacity
Recommended
Regenerative Resistor
Specifications
01 02 04 04 07 10 20
BR400W040 (400W 40Ω)
- - 8608 3506 2110 925 562
BR1K0W020 (1kW 20Ω)
- - - 8765 5274 2312 1406
ECMAE
0.5kW 1kW 1.5kw
2.0kW
(F130)
2.0kW
(F180)
3.0kW
Motor Capacity
Recommended
Regenerative Resistor
Specifications
05 1.0 15 20 20 30
BR400W040 (400W 40Ω)
291 283 213 163 68 -
BR1K0W020 (1kW 20Ω)
729 708 533 408 171 -
BR1K5W005 (3kW 10Ω)
- - - - - 331
ECMAF
3.0KW 4.5KW 5.5KW 7.5kW
Motor Capacity
Recommended
Regenerative Resistor
Specifications
30 45 55 75
BR1K5W005 (3kW 10Ω)
331 234 182 127
