Chapter 11 Specifications
Revision January 2011 11-7
C104
C106 C108 C110
ECMA Series
01
02 04 04 07 10 20
Brake power consumption
(at 20
o
C) [W]
7.3 6.5 6.5 8.2 8.2 19.4 19.4
Brake release time [ms (Max)] 5 10 10 10 10 10 10
Brake pull-in time [ms (Max)] 25 70 70 70 70 70 70
Vibration grade (μm)
15
Operating temperature
0
o
C t o 4 0
o
C (32
o
F to 104
o
F)
Storage temperature
-10
o
C to 80
o
C (-1 4
o
F to 176
o
F)
Operating humidity 20% to 90% RH (non-condensing)
Storage humidity 20% to 90% RH (non-condensing)
Vibration capacity 2.5G
IP Rating
IP65 (when waterproof connectors are used, or when an oil seal is used to be
fitted to the rotating shaft (an oil seal model is used))
Approvals
Footnote:
*1 Rate torque values are continuous permissible values at 0~40
o
C ambient temperature when
attaching with the sizes of heatsinks listed below:
ECMA-__04 / 06 / 08 : 250mm x 250mm x 6mm
ECMA-__10 : 300mm x 300mm x 12mm
ECMA-__13 : 400mm x 400mm x 20mm
ECMA-__18 : 550mm x 550mm x 30mm
Material type : Aluminum – F40, F60, F80, F100, F130, F180
NOTE
1) Please refer to Section 1.2 for details about the model explanation.
