Chapter 11 Specifications
Revision January 2011 11-11
F118
ECMA Series
30 45 55 75
Brake release time [ms (Max)] 10 10 10 10
Brake pull-in time [ms (Max)]
70 70 70 70
Vibration grade (μm)
15
Operating temperature
0
o
C t o 4 0
o
C (32
o
F to 104
o
F)
Storage temperature
-10
o
C to 80
o
C (-1 4
o
F to 176
o
F)
Operating humidity 20% to 90% RH (non-condensing)
Storage humidity 20% to 90% RH (non-condensing)
Vibration capacity 2.5G
IP Rating
IP65 (when waterproof connectors are used, or when an oil seal is used to be fitted to
the rotating shaft (an oil seal model is used))
Approvals
Footnote:
*1 Rate torque values are continuous permissible values at 0~40
o
C ambient temperature when
attaching with the sizes of heatsinks listed below:
ECMA-__04 / 06 / 08 : 250mm x 250mm x 6mm
ECMA-__10 : 300mm x 300mm x 12mm
ECMA-__13 : 400mm x 400mm x 20mm
ECMA-__18 : 550mm x 550mm x 30mm
Material type : Aluminum – F40, F60, F80, F100, F130, F180
NOTE
1) Please refer to Section 1.2 for details about the model explanation.
