Appendix A Accessories
Delta Part Number: ASD-CAPW2203, ASD-CAPW2205
(80mm)
(3.15 inch)
L
(100 mm)
(3.94 inch)
L
Title Part No. Straight
mm inch
1 ASD-CAPW2203 3106A-24-11S
3000  100 118  4
2 ASD-CAPW2205 3106A-24-11S
5000 100 197  4
Delta Part Number: ASD-CAPW2303, ASD-CAPW2305 (for motors with brake)
L
(100 mm)
(3.15 inch)
(3.94 inch)
(80mm)
L
Title Part No. Straight
mm inch
1 ASD-CAPW2303 3106A-24-11S
3000  100 118  4
2 ASD-CAPW2305 3106A-24-11S
5000 100 197  4
A-8 Revision January 2011
